All models with three-phase motors are standard supplied with CE control panel separate from the motor, and on demand are available panel control with timer, dry-stop, 24V output and remote radio control. The singlephase motors are supplied with a control box install on board of the motor.
The models available are the following:
|
Model |
Engine | Hp/kw | Speed | RPM | Capacity lt/h | Dimension |
Weight |
|
EURO 50 |
TF | 3 (2,2) | 1 | 430 | 7000 | 830x500x810 mm |
kg 43 |
| EURO 50 | MF | 3 (2,2) | 1 | 430 | 7000 | 830x500x810 mm | kg 43 |
| EURO 50 | TF | 2-3 (1,5-2,2) | 2 | 400 – 800 | 7000 – 12000 | 830x500x810 mm | kg 46 |
| EURO 60 | TF | 3 (2,2) | 1 | 430 | 15000 | 830x500x810 mm | kg 49 |
| EURO 60 | MF | 3 (2,2) | 1 | 430 | 15000 | 830x500x810 mm | kg 49 |
| EURO 60 | TF | 3-4 (2,2-3) | 2 | 400 – 800 | 15000 – 24000 | 830x500x810 mm |
kg 51 |
